3 Ton Semi Electric Rough Terrain Pallet Truck
The Voril 3 Ton Semi Electric Rough Terrain Pallet Truck is a heavy-duty material handling solution developed for transporting heavy palletized loads across warehouses, workshops, logistics yards, farms, construction sites and outdoor working areas.
Unlike a fully manual pallet truck, the CBD3T uses an electric drive system for traveling, while the forks are raised manually. This design combines the convenience of electric traveling with the simplicity of a manual lifting system.
With a 3,000 kg rated load capacity, large solid rubber drive wheel and high ground clearance, the CBD3T is particularly suitable for applications where conventional pallet trucks may have difficulty operating on rough, uneven or outdoor surfaces.
3 Ton Heavy-Duty Load Capacity
The CBD3T is designed with a 3,000 kg rated load capacity and a 500 mm load center, making it suitable for handling heavy palletized materials.
The 3-ton capacity provides the strength required for demanding industrial, warehouse, construction and logistics applications.
Typical heavy-load applications include:
Heavy machinery components
Industrial raw materials
Palletized building materials
Agricultural products
Manufacturing materials
Heavy warehouse goods
Logistics and distribution loads
Powerful 48V Electric Drive System
The CBD3T is equipped with a 48V permanent-magnet brushless maintenance-free drive motor with a power rating of 1,200 W.
The high-torque motor provides strong driving force for heavy loads and helps the machine maintain stable traveling performance in demanding working environments.
Because the travel function is electrically powered, operators do not need to manually push the loaded pallet truck, reducing physical effort during repeated transportation operations.
Drive System Features
48V electric drive system
1,200 W drive motor
Permanent-magnet brushless motor
Maintenance-free motor design
High torque output
Electric traveling
Suitable for heavy-load transportation
Large Φ300 × 100 mm Solid Rubber Drive Wheel
The large Φ300 × 100 mm solid rubber drive wheel is one of the key features of the CBD3T.
Compared with conventional pallet trucks equipped with smaller drive wheels, the large drive wheel provides better contact with the ground and improved ability to travel over rough and uneven surfaces.
The solid rubber construction provides good wear resistance and eliminates the need for regular inflation.
Combined with 100 mm ground clearance, the large drive wheel gives the pallet truck strong terrain adaptability for outdoor material handling.
Rough Terrain Design
Φ300 × 100 mm solid rubber drive wheel
100 mm ground clearance
Heavy-duty wear-resistant rubber
Strong traction
Improved uneven-ground mobility
Suitable for outdoor working conditions
Better adaptability to rough terrain
Patented Sealed Gear Transmission
The CBD3T adopts a patented fully sealed gear transmission system featuring a high transmission ratio, large-module gears and high-torque transmission.
The sealed transmission structure helps protect the internal gears and provides stable power transfer during heavy-load operation.
The transmission system is designed for:
High torque transmission
Stable operation
Reliable power delivery
Improved durability
Reduced maintenance requirements
Manual Fork Lifting
The CBD3T uses a manual fork lifting system rather than an electric lifting system.
The maximum fork lifting height is 200 mm, while the minimum fork ground clearance is 85 mm.
The manual lifting structure simplifies the machine configuration and helps keep the equipment economical while the electric travel system provides powered transportation.
This configuration is especially suitable for customers who need electric traveling but do not require frequent electric lifting.
Removable 48V Battery
The pallet truck uses a 48V 20Ah battery system.
The battery can be charged directly on the machine or removed and taken to another location for charging.
This is particularly useful for outdoor working environments where a fixed charging station may not be available.
When the machine is not being used, disconnecting the power plug can help reduce unnecessary battery discharge and contribute to longer battery service life.
Battery Features
48V battery
20Ah capacity
Removable battery design
On-board charging
Off-machine charging
Convenient for outdoor applications
Flexible charging options
Heavy-Duty Fork Design
The CBD3T is equipped with 1,160 mm long forks, with a fork width of 160 mm and fork thickness of 40 mm.
The heavy-duty fork structure is designed to provide stable support when transporting loads up to 3,000 kg.
Fork Specifications
| Item | Specification |
|---|---|
| Rated Load Capacity | 3,000 kg |
| Load Center | 500 mm |
| Fork Length | 1,160 mm |
| Fork Width | 160 mm |
| Fork Thickness | 40 mm |
| Minimum Fork Ground Clearance | 85 mm |
| Maximum Fork Lifting Height | 200 mm |
| Fork Inside Width | 230 / 365 mm |
| Fork Outside Width | 550 / 685 mm |
Compact Design and Maneuverability
Despite its 3-ton load capacity, the CBD3T maintains a relatively compact overall structure.
The pallet truck has an overall length of 1,700 mm, overall width of 685 mm and minimum turning radius of 1,550 mm.
This allows the machine to operate in warehouses, workshops, loading areas and other working environments where maneuverability is important.
Dimension Highlights
Overall length: 1,700 mm
Overall width: 685 mm
Overall height with handle: 1,380 mm
Overall height without handle: 700 mm
Minimum turning radius: 1,550 mm
Machine weight: 195 kg
Product Specifications
| Specification | Details |
|---|---|
| Product Type | Semi Electric Rough Terrain Pallet Truck |
| Model | CBD3T |
| Rated Load Capacity | 3,000 kg |
| Load Center | 500 mm |
| Travel Type | Electric |
| Lifting Type | Manual |
| Front Wheel | Rubber |
| Rear Wheel | UP / Nylon |
| Drive Wheel Size | Φ300 × 100 mm |
| Load Wheel Size | Φ80 × 70 mm |
| Ground Clearance | 100 mm |
| Minimum Fork Ground Clearance | 85 mm |
| Maximum Fork Lifting Height | 200 mm |
| Fork Inside Width | 230 / 365 mm |
| Fork Outside Width | 550 / 685 mm |
| Fork Width | 160 mm |
| Fork Length | 1,160 mm |
| Fork Thickness | 40 mm |
| Overall Length | 1,700 mm |
| Overall Width | 685 mm |
| Overall Height with Handle | 1,380 mm |
| Overall Height without Handle | 700 mm |
| Minimum Turning Radius | 1,550 mm |
| Gradeability, Loaded / Unloaded | 7% / 16% |
| Maximum Travel Speed, Loaded / Unloaded | 4 / 4.5 km/h |
| Battery | 48V 20Ah |
| Drive Motor Power | 1,200 W |
| Lifting | Manual |
| Lifting Speed, Loaded / Unloaded | 2.2 / 3.3 cm/s |
| Machine Weight | 195 kg |
Note: Since the CBD3T uses manual fork lifting, the specification should be displayed as Manual Lifting rather than listing a lift motor power.
Application Range
The 3 Ton Semi Electric Rough Terrain Pallet Truck is designed for heavy-duty pallet handling in environments where both high load capacity and terrain adaptability are important.
Warehouses
Suitable for transporting heavy pallets, raw materials, finished products and industrial goods across warehouse areas and loading zones.
Construction Sites
The large solid rubber drive wheel and high ground clearance make the CBD3T suitable for moving palletized building materials, equipment and construction supplies around job sites.
Farms and Agricultural Facilities
The rough terrain design allows the truck to handle palletized agricultural products, feed, fertilizer, machinery and other heavy materials.
Logistics Yards
Suitable for short-distance transportation of heavy pallets around loading areas, logistics yards and distribution facilities.
Manufacturing Facilities
The 3-ton load capacity makes the CBD3T suitable for moving heavy components, raw materials and finished products between production areas.
Workshops
The compact dimensions and electric travel system allow operators to move heavy loads efficiently between different working stations.
Outdoor Material Handling
With its 300 mm solid rubber drive wheel and 100 mm ground clearance, the truck provides improved mobility on rough and uneven outdoor surfaces compared with conventional warehouse pallet trucks.
Why Choose Voril CBD3T?
3 Ton Heavy-Duty Capacity
The 3,000 kg rated load capacity provides the strength required for demanding heavy-load pallet handling applications.
Electric Travel
The 48V electric drive system reduces operator effort and makes repeated pallet transportation more efficient.
Manual Lifting
The manual lifting structure keeps the machine simple, practical and economical.
Strong Rough Terrain Capability
The Φ300 × 100 mm solid rubber drive wheel and 100 mm ground clearance improve mobility on rough and uneven surfaces.
Removable Battery
The removable 48V 20Ah battery allows flexible charging both on and off the machine.
Low-Maintenance Drive System
The permanent-magnet brushless motor is maintenance-free, while the sealed gear transmission provides stable and reliable power transmission.
Flexible Working Environment
The combination of electric travel, manual lifting, large solid rubber wheels and high ground clearance makes the CBD3T suitable for both indoor and outdoor material handling applications.
FAQ
1. What is a semi electric rough terrain pallet truck?
A semi electric rough terrain pallet truck uses an electric motor for traveling while the forks are raised manually. It combines powered transportation with a simple manual lifting system and is designed for rough or uneven working environments.
2. What is the load capacity of the CBD3T?
The CBD3T has a 3,000 kg rated load capacity and a 500 mm load center.
3. Is the CBD3T fully electric?
No. The CBD3T is a semi electric pallet truck. Traveling is powered by a 48V electric motor, while fork lifting is performed manually.
4. Can the CBD3T be used outdoors?
Yes. The CBD3T is designed for demanding working environments and features a Φ300 × 100 mm solid rubber drive wheel and 100 mm ground clearance for improved mobility on rough and uneven surfaces.
5. How high can the forks lift?
The maximum fork lifting height is 200 mm.
6. What battery does the CBD3T use?
The standard battery specification is 48V 20Ah.
7. Can the battery be removed?
Yes. The battery can be removed from the machine and charged separately, providing greater flexibility when working away from fixed power outlets.
8. What is the drive motor power?
The CBD3T uses a 1,200 W 48V permanent-magnet brushless drive motor.
9. What makes the CBD3T suitable for rough terrain?
The main features include the large Φ300 × 100 mm solid rubber drive wheel and 100 mm ground clearance, which provide better ground contact, traction and terrain adaptability.
10. Is the CBD3T suitable for construction sites?
Yes. Its 3-ton load capacity, large solid rubber drive wheel and high ground clearance make it suitable for many construction-site material handling applications.
11. What industries can use the CBD3T?
The CBD3T can be used in warehousing, logistics, manufacturing, construction, agriculture, workshops and outdoor material handling.
12. Can Voril customize the pallet truck?
Yes. Voril can discuss customized configurations according to the customer's application, working environment, fork dimensions, battery requirements and other material handling needs.
CTA
Looking for a 3 Ton Semi Electric Rough Terrain Pallet Truck?
If you need a 3 Ton Semi Electric Rough Terrain Pallet Truck for heavy-load transportation, outdoor material handling or uneven working environments, the Voril CBD3T provides a practical combination of electric traveling, manual lifting, high load capacity and rough terrain capability.
Contact Voril today to get the latest price, technical specifications, battery options and customized solutions for your material handling requirements.
Please send us your requirements, including:
Required load capacity
Working environment
Fork dimensions
Battery requirements
Required quantity
Destination country
Voril — Practical Material Handling Solutions for Your Business.
