800 kg 3-Wheel Fully Electric Forklift
The CPD-08 800 kg 3-Wheel Fully Electric Forklift is designed for customers who require more lifting capacity while maintaining a compact three-wheel operating structure.
The forklift uses two front drive wheels and two centrally positioned rear steering wheels, forming a three-point support structure.
With an 800 kg rated load capacity and 500 mm load center, the CPD-08 is suitable for pallet handling, warehouse storage, manufacturing material movement and indoor logistics.
Its 2,500 mm lifting height provides additional stacking capability compared with the CPD-05.
Three-Point Counterbalance Structure
The three-point configuration provides:
Two front drive wheels
Centralized rear steering
Three-point ground support
Counterbalance structure
Compact chassis
Responsive steering
The centralized steering structure helps reduce the operating space required for turning.
2,000 mm Turning Radius
The CPD-08 has a specified 2,000 mm turning radius.
This makes it suitable for:
Warehouse aisles
Storage racks
Production workshops
Loading areas
Logistics centers
Indoor transportation
Elevator-accessed areas
The compact steering structure can help improve maneuverability in space-limited facilities.
Fully Electric Travel and Lifting
The CPD-08 uses fully electric travel and lifting.
The electric configuration provides:
Zero direct exhaust emissions
Low operating noise
Smooth travel
Precise low-speed control
Reduced operator effort
Efficient indoor handling
This makes it suitable for warehouses, workshops and production environments where clean operation is important.
3,000 W Dual Drive System
The CPD-08 uses a dual-drive system with a specified 3,000 W drive motor power.
The system provides:
Responsive acceleration
Independent front-wheel drive
Smooth low-speed movement
Precise maneuvering
Efficient power utilization
The dual-drive configuration is suitable for frequent indoor handling operations.
1,800 W Lifting Motor
The CPD-08 uses a 1,800 W lifting motor.
The lifting system supports the vehicle's 800 kg rated load capacity and 2,500 mm lifting height under specified operating conditions.
The electric lifting system provides controlled fork movement for pallet handling and stacking.
2,500 mm Lifting Height
The CPD-08 provides a 2,500 mm lifting height.
The configuration is suitable for:
Pallet stacking
Medium-height rack storage
Warehouse operations
Manufacturing material handling
Loading and unloading
The standard fork length is 1,070 mm.
Wide-View Mast and Operator Visibility
The wide-view mast improves the operator's forward view.
The large-radius overhead guard and optimized roof panel angle also help increase visibility above the operator.
This supports better observation during:
Pallet positioning
Rack approach
Lifting operations
Stacking
Indoor transportation
Intelligent LCD Display
The LCD display can show vehicle operating conditions and fault information.
The control system can provide:
Fault code display
Incorrect-operation alarms
Turning-speed reduction
Overload protection
Emergency power cut-off
Ramp anti-rollback
These functions provide additional support for daily forklift operation.
Comfortable Seated Operation
The CPD-08 uses a seated operating design.
The steering wheel and seat can be adjusted to suit different operators.
The configuration helps:
Reduce fatigue
Improve driving comfort
Improve steering control
Support extended operating periods
The ratchet-type parking brake helps provide controlled parking on both level surfaces and ramps.
Energy-Efficient Design
The CPD-08 can use dedicated electric forklift tires and regenerative braking.
The system is designed to improve energy utilization during repeated acceleration, travel and braking.
LED signal lights and professionally matched electrical components also contribute to efficient operation.
Compact Vehicle Dimensions
The CPD-08 has:
Overall length: 1,850 mm
Overall width: 920 mm
Overall height with forks lowered: 1,910 mm
Overall height with forks raised: 3,510 mm
Fork length: 1,070 mm
Maximum fork width: 800 mm
Minimum fork ground clearance: 35 mm
Turning radius: 2,000 mm
Technical Specifications
| Specification | CPD-08 |
|---|---|
| Product Type | 3-Wheel Fully Electric Counterbalance Forklift |
| Model | CPD-08 |
| Rated Load Capacity | 800 kg |
| Load Center | 500 mm |
| Operating Type | Seated |
| Battery / Power Type | Pure Electric Drive |
| Tire Type | Rubber |
| Drive Wheel Size | Φ400 × 100 / 300 × 95 mm |
| Load Wheel Size | Φ68 × 20 mm |
| Balance Wheel Size | Φ37 × 33 mm |
| Wheel Quantity Specification | 14 |
| Lifting Height | 2,500 mm |
| Overall Height, Forks Lowered | 1,910 mm |
| Overall Height, Forks Raised | 3,510 mm |
| Minimum Fork Ground Clearance | 35 mm |
| Overall Length | 1,850 mm |
| Overall Width | 920 mm |
| Fork Length | 1,070 mm |
| Maximum Fork Width | 800 mm |
| Turning Radius | 2,000 mm |
| Travel Speed, Loaded / Unloaded | 11 / 13 km/h |
| Lifting Speed | 2,000 / 19 mm/s |
| Lowering Speed | 2,000 / 15 mm/s |
| Gradeability, Loaded / Unloaded | 5 / 8% |
| Braking System | Oil Braking |
| Drive Motor Power | 3,000 W |
| Lifting Motor Power | 1,800 W |
| Electrical System | 60V / 70Ah |
| Control System | MOS Stepless Speed Control |
Final product specifications should be confirmed according to the actual production configuration.
Safety Design
| Safety Feature | Function |
|---|---|
| Wide-View Mast | Improves visibility |
| Hydraulic Hose Burst Protection | Helps reduce uncontrolled lowering risk |
| LCD Fault Display | Displays vehicle status and fault information |
| Incorrect-Operation Alarm | Provides operating warnings |
| Overload Protection | Helps protect the vehicle |
| Emergency Power Cut-Off | Provides rapid power interruption |
| Turning-Speed Reduction | Helps improve turning stability |
| Ramp Anti-Rollback | Helps reduce unintended movement |
| Parking Brake | Supports secure parking |
Core Advantages
1. 800 kg Rated Capacity
Suitable for light-to-medium pallet handling.
2. Three-Point Counterbalance Design
Combines compact structure with responsive steering.
3. 2,000 mm Turning Radius
Suitable for relatively narrow working areas.
4. 2,500 mm Lifting Height
Provides additional stacking capability.
5. 3,000 W Drive Motor
Provides responsive electric travel performance.
6. 1,800 W Lifting Motor
Supports repeated lifting operations.
7. 60V / 70Ah Electrical System
Provides electrical power for travel, lifting and control systems.
8. Wide Operator Visibility
Wide-view mast and overhead guard design improve visibility.
Typical Applications
Warehouse & Storage — pallet stacking and internal transportation.
Manufacturing — production material movement.
Logistics & Distribution — pallet transportation and loading-area handling.
Retail & Wholesale — handling palletized goods.
Workshop Operations — compact material handling in production areas.
OEM & Customization
Customization may include:
Machine color
Logo
Nameplate
Fork dimensions
Lifting height
Battery configuration
Charger
Safety equipment
Packaging
Application-specific configuration
FAQ
What is the rated capacity?
The CPD-08 has an 800 kg rated load capacity.
What is the load center?
The standard load center is 500 mm.
What is the lifting height?
The standard lifting height is 2,500 mm.
What is the turning radius?
The turning radius is 2,000 mm.
Is it fully electric?
Yes. It uses fully electric travel and lifting.
What is the drive motor power?
The drive motor power is 3,000 W.
What is the lifting motor power?
The lifting motor power is 1,800 W.
What is the electrical system?
The specified system is 60V / 70Ah.
Can the forklift be customized?
Yes. Lifting height, forks, battery and other configurations can be customized according to requirements.
Request a Quote
Looking for an 800 kg 3-Wheel Fully Electric Forklift?
Send us your required:
Load capacity, lifting height, pallet dimensions, rack height, aisle width, working environment, operating hours and battery requirements.
Our team can recommend a suitable CPD-08 configuration according to your application.
Contact us today for specifications, configuration options and a quotation.
