500 kg 3-Wheel Fully Electric Forklift
The CPD-05 500 kg 3-Wheel Fully Electric Forklift is a compact electric counterbalance forklift developed for applications where maneuverability, compact dimensions and clean electric operation are important.
Unlike a conventional four-wheel forklift, the CPD-05 uses a three-point support structure. The front section is equipped with two drive wheels, while the rear section uses two centrally arranged steering wheels. This structure provides a compact steering layout and allows the forklift to operate efficiently in restricted spaces.
The CPD-05 has a 490 kg rated load capacity, corresponding to the 500 kg class, with a 500 mm load center and a standard 2,000 mm lifting height.
It is particularly suitable for warehouses, workshops, production areas, retail storage facilities and other indoor applications where a compact forklift is required.
Three-Point Counterbalance Structure
The CPD-05 is a three-wheel counterbalance forklift based on a three-point support structure.
The vehicle configuration includes:
Two front drive wheels
Two centrally arranged rear steering wheels
Three-point ground support
Counterbalance structure
Compact chassis
Centralized rear steering
The rear steering wheels are positioned in the center of the rear section, allowing the forklift to turn within a relatively small operating area.
This structure is one of the key differences between a 3-wheel electric forklift and a conventional four-wheel forklift.
Small Turning Radius
The CPD-05 provides a 1,600 mm turning radius.
The compact turning configuration makes it suitable for applications where available operating space is limited.
Typical applications include:
Narrow warehouse aisles
Small storage areas
Production workshops
Loading areas
Retail warehouses
Elevator-accessed areas
Indoor material handling
For customers trying to maximize available storage space, a compact three-wheel forklift can help reduce the operating space required around storage racks.
Fully Electric Travel and Lifting
The CPD-05 uses a fully electric travel and lifting system.
The electric configuration provides:
Fully electric travel
Fully electric lifting
Low operating noise
Zero direct exhaust emissions
Smooth acceleration
Precise low-speed movement
Reduced operator effort
Suitable indoor operation
The electric power system makes the CPD-05 particularly suitable for enclosed facilities where exhaust emissions and operating noise need to be minimized.
Dual Electric Drive System
The CPD-05 uses a dual-drive configuration with the front drive wheels independently powered.
The specified drive motor power is 1,500 W.
The dual-drive structure helps provide:
Responsive acceleration
Precise low-speed control
Smooth movement
Flexible steering
Independent wheel drive
Efficient power transmission
The system is especially useful for frequent start-stop operations in warehouses and workshops.
48V Electrical System
The CPD-05 uses a 48V / 46Ah electrical system.
The electrical system supplies power for the vehicle's travel, lifting and control functions.
The compact electrical configuration is suitable for light-duty indoor handling applications.
The battery configuration can be selected according to the actual production configuration and customer requirements.
2,000 mm Lifting Height
The standard CPD-05 provides a 2,000 mm lifting height.
This configuration is suitable for:
Low-level pallet stacking
Warehouse storage
Production material handling
Loading and unloading
Indoor transportation
Workshop operations
The lifting height can be customized according to the application and mast configuration.
Wide-View Mast
The CPD-05 adopts a wide-view mast design to improve operator visibility during travel and lifting.
The mast can provide a clearer forward view of:
Forks
Pallets
Storage racks
Working areas
Elevated loads
A hydraulic hose burst protection configuration can also be provided to help reduce the risk of uncontrolled lowering caused by hydraulic hose failure.
Enhanced Operator Visibility
The operator visibility system combines:
Wide-view mast
Large-radius overhead guard
Optimized roof panel angle
Increased upward visibility
Improved forward visibility
The optimized overhead guard structure increases the operator's view above the head, which is useful when positioning loads at elevated levels.
LCD Display and Fault Information
The CPD-05 can be equipped with a large LCD display.
The display allows the operator to monitor vehicle operating conditions and fault information more intuitively.
The intelligent control system can provide functions including:
Vehicle status display
Fault code display
Incorrect-operation alarm
Turning-speed reduction
Overload protection
Emergency power cut-off
Ramp anti-rollback
These functions help operators identify abnormal operating conditions and improve daily operating safety.
Comfortable Operator Design
The CPD-05 uses a seated operating configuration.
The steering wheel and seat can be adjusted to help the operator find a suitable driving position.
The ergonomic configuration helps:
Reduce operator fatigue
Improve driving comfort
Provide better steering control
Support repeated handling operations
The ratchet-type parking brake is designed to provide appropriate braking force for different operating conditions, including level ground and ramps.
Energy-Efficient Design
The CPD-05 is designed with several energy-saving features.
The vehicle can use dedicated electric forklift tires to reduce rolling resistance and improve travel efficiency.
The electric system can also incorporate regenerative braking to recover part of the braking energy.
Other energy-efficient components include:
LED signal lights
Efficient electric drive system
Regenerative braking
Professionally matched electrical components
Optimized motor control
These features help reduce energy consumption during repeated material handling operations.
Compact Vehicle Dimensions
The CPD-05 has a compact body suitable for confined working areas.
The main dimensions include:
Overall length: 1,530 mm
Overall width: 780 mm
Overall height with forks lowered: 1,600 mm
Overall height with forks raised: 2,610 mm
Fork length: 750 mm
Maximum fork width: 530 mm
Minimum fork ground clearance: 40 mm
Turning radius: 1,600 mm
Before selecting the forklift, customers should compare the overall dimensions with their aisle width, doorway dimensions, rack layout and operating area.
Technical Specifications
| Specification | CPD-05 |
|---|---|
| Product Type | 3-Wheel Fully Electric Counterbalance Forklift |
| Model | CPD-05 |
| Rated Load Capacity | 490 kg |
| Product Class | 500 kg Class |
| Load Center | 500 mm |
| Operating Type | Seated |
| Battery Type | Chaowei Battery |
| Tire Type | Rubber |
| Drive Wheel Size | Φ400 × 100 / 300 × 95 mm |
| Load Wheel Size | Φ68 × 20 mm |
| Balance Wheel Size | Φ37 × 33 mm |
| Wheel Quantity Specification | 13 |
| Lifting Height | 2,000 mm |
| Overall Height, Forks Lowered | 1,600 mm |
| Overall Height, Forks Raised | 2,610 mm |
| Minimum Fork Ground Clearance | 40 mm |
| Overall Length | 1,530 mm |
| Overall Width | 780 mm |
| Fork Length | 750 mm |
| Maximum Fork Width | 530 mm |
| Turning Radius | 1,600 mm |
| Travel Speed, Loaded / Unloaded | 8 / 10 km/h |
| Lifting Speed | 2,000 / 19 mm/s |
| Lowering Speed | 2,000 / 15 mm/s |
| Gradeability, Loaded / Unloaded | 5 / 8% |
| Braking System | Mechanical Braking |
| Drive Motor Power | 1,500 W |
| Lifting Motor Power | 1,200 W |
| Electrical System | 48V / 46Ah |
| Control System | MOS Stepless Speed Control |
Final product specifications should be confirmed according to the actual production configuration.
Safety Design
| Safety Feature | Function |
|---|---|
| Wide-View Mast | Improves operator visibility |
| Hydraulic Hose Burst Protection | Helps reduce uncontrolled lowering risk |
| LCD Fault Display | Displays operating and fault information |
| Incorrect-Operation Alarm | Provides operating warnings |
| Overload Protection | Helps protect the vehicle during overload conditions |
| Emergency Power Cut-Off | Allows rapid power interruption |
| Turning-Speed Reduction | Helps improve stability during turning |
| Ramp Anti-Rollback | Helps reduce unintended movement on slopes |
| Ratchet Parking Brake | Provides controlled parking braking |
Core Advantages
1. 500 kg Class Capacity
The CPD-05 provides a 490 kg rated load capacity, making it suitable for light-duty pallet and material handling.
2. Three-Point Counterbalance Structure
The three-point design combines compact dimensions with responsive steering.
3. 1,600 mm Turning Radius
The small turning radius provides excellent maneuverability in restricted areas.
4. Fully Electric Operation
Electric travel and lifting provide low-noise and zero-direct-emission operation.
5. Dual Drive System
The dual front-wheel drive system provides responsive and precise movement.
6. Wide-View Design
The wide-view mast and optimized overhead guard improve operator visibility.
7. Comfortable Operation
Adjustable steering wheel and seat help reduce operator fatigue.
8. Intelligent Safety Control
LCD display, fault alarms, emergency power cut-off and other control functions improve operating safety.
9. Compact Dimensions
The 1,530 mm overall length and 780 mm overall width provide a compact operating profile.
Typical Applications
Warehouse & Storage
Low-level pallet stacking, internal transportation and warehouse material handling.
Manufacturing
Moving components, raw materials and finished products around production areas.
Logistics & Distribution
Short-distance pallet transportation and loading-area operations.
Retail & Wholesale
Handling palletized products in compact storage facilities.
Workshops
Suitable for material handling in relatively confined production and maintenance areas.
OEM & Customization
Customization options may include:
Machine color
Company logo
Nameplate
Fork dimensions
Lifting height
Battery configuration
Charger
Safety equipment
Packaging
Application-specific configurations
OEM and customized configurations can be discussed according to the customer's application and order requirements.
FAQ
What is the rated load capacity of the CPD-05?
The CPD-05 has a 490 kg rated load capacity and belongs to the 500 kg class.
Is the CPD-05 a fully electric forklift?
Yes. The CPD-05 is designed with fully electric travel and lifting systems.
What is the load center?
The standard load center is 500 mm.
What is the lifting height?
The standard lifting height is 2,000 mm.
What is the turning radius?
The specified turning radius is 1,600 mm.
What type of forklift is the CPD-05?
It is a 3-wheel fully electric counterbalance forklift with a seated operating configuration.
What is the drive motor power?
The specified drive motor power is 1,500 W.
What is the lifting motor power?
The specified lifting motor power is 1,200 W.
What is the electrical system?
The CPD-05 uses a 48V / 46Ah electrical system.
Can the lifting height be customized?
Yes. The lifting configuration can be customized according to application requirements.
