| Model | T480 |
| Operating Weight | 1321kgs |
| Bucket Capacity | 0.1m3 |
| Climbing Ability | 25° |
| Maximum Breakout Force | 4.5KN |
| Rated Load | 350kg |
| Maximum Load | 450kg |
| Travel Speed | 0-5km/h |
| Vehicle Width | 1040mm |
| Rated Pressure | 16Mpa |
| Bucket Width | 1050mm |
| Max Loading Height | 1720mm |
| Max Dumping Height | 1401mm |
| Max Operating Height | 2110mm |
| Height to Bucket Pin | 1870mm |
| Max Height Bucket Dump Angle | 63° |
| Min Height | 1300mm |
| Departure Angle | 22° |
| Ground Clearance | 157mm |
| Dumping Distance | 295mm |
| Track Contact Length | 900mm |
| Overall Dismensions | 2169*1120*1300mm |
| Length including Bucket | 2169mm |
| Length excluding Bucket | 1850mm |
| Track Model | 180*72*35 |
| Engine Brand | Yanmar/Kubato |
| Model | 3TNV80/D1105 |
| Rated Power | 15.2(17.8)/17.1KW |
| Cylinder | 3 |
| Intake Method | Natural Inhalation |
| Emission Standard | EPA/EURO5 |
| Fuel Tank Capacity | 13L |
