| Model | T390 |
| Operating Weight | 1070kgs |
| Bucket Capacity | 0.1m3 |
| Climbing Ability | 25° |
| Maximum Breakout Force | 3.5KN |
| Rated Load | 250kg |
| Maximum Load | 300kg |
| Travel Speed | 0-5km/h |
| Vehicle Width | 955mm |
| Rated Pressure | 16Mpa |
| Bucket Width | 1050mm |
| Max Loading Height | 1830mm |
| Max Dumping Height | 1404mm |
| Max Operating Height | 2488mm |
| Height to Bucket Pin | 1899mm |
| Max Height Bucket Dump Angle | 63° |
| Min Height | 1300mm |
| Departure Angle | 40° |
| Ground Clearance | 219mm |
| Dumping Distance | 526mm |
| Track Contact Length | 1300mm |
| Overall Dismensions | 2282*1050*1300mm |
| Length including Bucket | 2282mm |
| Length excluding Bucket | 1880mm |
| Track Model | 180*72*45 |
| Engine Brand | Lithium Electricity/Koop/Rato/B&S |
| Model | Lead-acid Batter/192FH/R420D/XR13.5 |
| Rated Power | 6KW,72V,125AH/7.6(7)/7.9/9.92KW |
| Cylinder | 1 |
| Intake Method | Natural Inhalation |
| Emission Standard | EPA/EURO5 |
| Fuel Tank Capacity | 5L |
