| Model | S390 |
| Operating Weight | 989kgs |
| Bucket Capacity | 0.1m3 |
| Climbing Ability | 25° |
| Maximum Breakout Force | 3.5KN |
| Rated Load | 260kg |
| Maximum Load | 290kg |
| Travel Speed | 0-6km/h |
| Vehicle Width | 959mm |
| Rated Pressure | 16Mpa |
| Bucket Width | 1050mm |
| Max Loading Height | 2460mm |
| Max Dumping Height | 1376mm |
| Max Operating Height | 2460mm |
| Height to Bucket Pin | 1872mm |
| Max Height Bucket Dump Angle | 63° |
| Min Height | 1300mm |
| Departure Angle | 18° |
| Ground Clearance | 193mm |
| Dumping Distance | 600mm |
| Wheelbase | 800mm |
| Overall Dismensions | 2281*1050*1300mm |
| Length including Bucket | 2281mm |
| Length excluding Bucket | 1880mm |
| Tire Model | 23*8.5-12 |
| Engine Brand | Lithium Electricity/Koop/Rato/B&S |
| Model | Lead-acid Batter/192FH/R420D/XR13.5 |
| Rated Power | 6KW,72V,125AH/7.6(7)/7.9/9.92KW |
| Cylinder | 1 |
| Intake Method | Natural Inhalation |
| Emission Standard | EPA/EURO5 |
| Fuel Tank Capacity | 5L |
