| Model | S55 |
| Operating Weight | 3845kgs |
| Bucket Capacity | 0.4m3 |
| Climbing Ability | 25° |
| Maximum Breakout Force | 25KN |
| Rated Load | 890kg |
| Maximum Load | 1780kg |
| Travel Speed | 0-12km/h |
| Hydraulic Flow Rate | 55L/Min |
| Hydraulic Pressure | 21Mpa |
| Bucket Width | 1800mm |
| Max Loading Height | 2846mm |
| Max Dumping Height | 2384mm |
| Max Operating Height | 3790mm |
| Height to Bucket Pin | 3020mm |
| Max Height Bucket Dump Angle | 63° |
| Min Height | 2095mm |
| Tail Length | 1160mm |
| Ground Clearance | 185mm |
| Dumping Distance | 520mm |
| Wheelbase | 1200mm |
| Overall Dismensions | 3450*1800*2095mm |
| Length including Bucket | 3450mm |
| Length excluding Bucket | 2700mm |
| Tire Model | 10-10.5 |
| Engine Brand | YANMAR/CUMMINS |
| Model | 4TNV80/HFC4DA 1-2C3 |
| Rated Power | 35.5/36.8KW |
| Cylinder | 4 |
| Intake Method | Natural Inhalation |
| Emission Standard | EPA/EURO5 |
| Fuel Tank Capacity | 80L |
